Precision Row Seeding
Adjustable Row Spacing
DJI & XAG Compatible
1–13 kg/mu Seeding Rate
Autonomous Flight Support
The Precision Row Seeding Module is designed for controlled row seeding with agricultural drones.
Unlike conventional centrifugal broadcasting systems, this module places seeds in organized rows with adjustable spacing, helping improve seed distribution and field management.
The modular system supports quick installation and removal and can be integrated with DJI, XAG, and other compatible agricultural drone platforms.
It is suitable for applications requiring more controlled and precise seeding operations.
1， Precision Row Seeding：Places seeds in controlled rows instead of conventional centrifugal broadcasting.
2 ，Adjustable Row Spacing：Row spacing can be adjusted according to different crops and planting requirements.
3，Seed-Friendly Feeding：The flexible seed feeding system is designed to reduce damage to seeds during the seeding process.
4，Ground-Hugging Seeding：The extended seeding outlets help maintain a closer distance to the ground, reducing the influence of wind during seed distribution.
5，Quick-Release Modular Design：Designed for convenient installation, removal, and integration with compatible agricultural drones.
DJI T55，DJI T60，DJI T70P，DJI T70S，DJI T100，XAG P150，XAG P200
Other compatible agricultural drones
Please contact us with your drone model to confirm compatibility.
| Specification | Details |
|---|---|
| Total Weight | Approx. 17.5 kg |
| Dimensions – Unfolded | 2035 × 1570 × 835 mm |
| Dimensions – Folded | 1950 × 1570 × 705 mm |
| Capacity per Module | 10 L |
| Number of Modules | 4–6 pcs |
| Maximum Seed Capacity | Approx. 50 kg |
| Seeding Width | 90–150 cm |
| Seeding Rate | 1–13 kg/mu |
| Recommended Flight Speed | 4–7 m/s |
| Recommended Seeding Height | 15 ± 5 cm above the ground |
| Operating Voltage | 50 V |
| Power Supply | Aircraft power supply |
| Control Method | Independent remote control / up to 1 km |
| Seed Detection | Seed deficiency detection |
| Seeding Mode | Autonomous flight + manual seeding |
| Compatible Platforms | DJI, XAG and other supported agricultural drones |
1，Which drones are compatible with this row seeding module?
The module supports DJI and XAG agricultural drones, including T55, T60, T70P, T70S, T100, P150, and P200, as well as other compatible platforms.
2，How many seeding modules can be installed?
The system supports 4 to 6 modules.
3，What is the maximum seed capacity?
The maximum seed carrying capacity is approximately 50 kg.
4，Can the row spacing be adjusted?
Yes. The system supports adjustable row spacing to meet different crop and planting requirements.
5，How is this different from centrifugal broadcasting?
Instead of scattering seeds through centrifugal broadcasting, this system places seeds in controlled rows for more organized seed distribution.
6，Does the system support autonomous operation?
Yes. The system supports autonomous flight combined with manual seeding operation.
7，Can the system detect seed shortages?
Yes. The system includes a seed deficiency detection function with warning prompts.
8，What is the recommended flight speed?
The recommended flight speed is 4–7 m/s.
9，How close should the seeding outlets be to the ground?
The recommended distance is approximately 15 ± 5 cm above the ground.
